HXGN15-12 (SF6) unit-type AC metal-enclosed ring network switchgear (hereinafter referred to as ring network cabinet) is a new generation of high-voltage electrical products designed and developed by us after introducing foreign advanced technology and in accordance with the requirements of domestic rural power and urban network transformation. All technical performance indicators meet the IEC62271-200:2011 and GB3906 standards.

The main switch, operating mechanism and components of the ring network cabinet adopt ABB original parts or SFL-12/24 switchgear assembled and produced domestically with imported parts. It can also be equipped with ABB original HAD/US type SF6 circuit breaker or VD4-S type vacuum circuit breaker according to user needs. Its operation mode is divided into manual and electric.

The cabinet is riveted after CNC machine processing, and the protection level reaches IP3X, and it has reliable mechanical interlocking and anti-misoperation functions. This product has very significant characteristics such as small size, light weight, beautiful appearance, easy operation, long life, high parameters, no pollution, and less maintenance.

HXGN15-12 (SF6) unit-type AC metal-enclosed ring network switchgear is suitable for receiving and distributing electric energy in AC 50Hz, 12kV power networks.
